| Chassis format | All-in-one (single/dual controllers, internal drive bays, networking) with expansion options |
| Rack size | 2U | | |
| Controllers | 2 hot-swappable per chassis (dual active) | | |
| Single/dual controller support for 2U |
| Processors | | | |
| Internal storage | 12 x 3.5” drive bays (2.5” drive carriers supported) | | |
| System memory | 16GBper controller (32GB total) | | |
| Expansion Capacity |
| Min/Max drive count | 2/264 | | |
| Max raw capacity | 2.40PB (with 9xME412 expansion) | | |
| 1.83PB (with 9xME424 expansion) |
| 1.89PB (with 9xME424 expansion) |
| 5.28PB (with 3xME484 expansion) |
| NAS Support | Supported with NX Series Windows NAS appliance |
| Storage media | SAS and NL-SAS drives; different drive types, transfer rates, rotational speeds can be mixed in the same system: |
|
| NLSAS 7.2K 3.5” – 4TB, 8TB, 12TB, 16TB, 16TB FIPS, 20TB |
| SAS 10K 2.5” – 1.2TB, 2.4TB, 2.4TB FIPS |
| SSD – 960GB RI, 1.6TB MU, 1.92TB, 3.84TB, 3.84TB FIPS, 7.68TB RI |
| SDD and HDD: FIPS-certified SEDs |
|
| Network and Expansion I/O |
| Host interface | FC, iSCSI (optical or BaseT), SAS |
| Max 32Gb FC ports | 8 per array (support auto-negotiate to 16Gb) |
| Max 25Gb iSCSI ports | 8 SFP+ or SFP28 ports per array |
| Max 10Gb iSCSI ports | 8 BaseT ports per array (only support auto negotiate to 1Gb) |
| Max 12Gb SAS ports | 8 12Gb SAS ports |
| Max management ports | 2 per array (1Gb BASE-T) |
| Disk expansion protocol | 12Gb SAS |
| Disk interface expansion ports | 2 12Gb SAS (wide-Port) per array (1 port per controller) |
| Up to 9 2U expansion enclosures per 2U base array |
| Up to 3 5U expansion enclosures per 2U base array |
| Up to 3 5U expansion enclosures per 5U base array |
| Physical |
| Rack size | 2U | | |
| Height | 8.79 cm (3.46 inches) | | |
| Width | 48.30 cm (19.01 inches) | | |
| Depth | 61.87mm (24.36 inches) | | |
| Weight at max configuration | 32.00 kg (71.00 lbs) | | |
| Weight empty | 4.80 kg (10.56 lbs) without drives | | |
| Power |
| Power/wattage | 580W | | |
| Heat dissipation | 1980 BTU | | |
| Voltage | 100-240 VAC | | |
| Frequency | 50/60 Hz | | |
| Amperage | 7.6-3.0A (x2) | | |
| Environmental Operating Conditions |
| Operating temperature | 5°C – 35°C (41°F – 95°F, derated by 1°C per 300mm above 900m) |
| Non-operating temperature | -40°C to 70°C (-40 to 158°F) Maximum temperature changes in an hour: 20°C |
| Operating humidity ranges (non-condensing) | -12C dew point minimum, 8% to 85% maximum, non-condensing |
| Non-operating humidity (noncondensing) | 21°C dew point maximum, 5% to 100% maximum, non-condensing |
| Services, Warranties |
| Services | Dell ProSupport Enterprise Suite and DellProDeploy Enterprise Suite. Optional ProSupport Plus is available offering pro-active and preventative services to improve performance and stability. |
| System sizing | Dell Power Sizer |
| | | |
