Technical Specifications
Processor • Up to two 3rd Generation Intel Xeon Scalable processors, with up to 24 cores per processor
Memory • Memory 16 DDR4 DIMM slots, supports RDIMM max 1 TB, speeds up to 2933 MT/s
Storage controllers • Internal controllers (RAID): PERC H345, PERC H355, HBA355i, PERC H745, PERC H755, S150
• Internal Boot: Internal Dual SD Module or Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2x M.2 SSDs or USB
• External PERC (RAID): PERC H840
• External HBA (non-RAID) HBA355e
Drive Bays Front bays:
• Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB
• Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 61.4 TB
Power Supplies • 600W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap redundant
• 800W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap redundant
• 1100W -48Vdc hot swap redundant (CAUTION: only works with -48Vdc to -60Vdc power input)
Cooling options Air cooling
Fans • Standard (STD) fans or High performance SLVR fans
• Up to seven cold swap fans
Dimensions • Height – 42.8 mm (1.7 inches)
• Width – 482 mm (18.97 inches)
• Depth – 734.95 mm (28.92 inches) – without bezel
748.79 mm (29.47 inches) – with bezel
Form Factor 1U rack server
Embedded Management • iDRAC9
• iDRAC Direct
• iDRAC RESTful API with Redfish
• iDRAC Service Module
• Quick Sync 2 wireless module
Bezel Optional LCD bezel or security bezel
OpenManage Software • OpenManage Enterprise
• OpenManage Power Manager plugin
• OpenManage SupportAssist plugin
• OpenManage Update Manager plugin
Mobility OpenManage Mobile
Integrations and Connections OpenManage Integrations
• BMC Truesight
• Microsoft System Center
• Red Hat Ansible Modules
• VMware vCenter and vRealize Operations Manager
OpenManage Connections
• IBM Tivoli Netcool/OMNIbus
• IBM Tivoli Network Manager IP Edition
• Micro Focus Operations Manager
• Nagios Core
• Nagios XI
Security • Cryptographically signed firmware
• Secure Boot
• Secure Erase
• Silicon Root of Trust
• System Lockdown (requires iDRAC9 Enterprise or Datacenter)
• TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Embedded NIC 2 x 1 GbE LOM
Network Options 1 x OCP 3.0
GPU Options NA
Ports Front Ports
• 1 x Dedicated iDRAC Direct micro-USB
• 1 x USB 3.0
• 1 x VGA
Rear Ports
• 1 x USB 2.0
• 1 x Serial (optional)
• 1 x iDRAC ethernet port
• 1 x USB 3.0
• 2 x Ethernet
• 1 x VGA
Internal Ports
• 1 x USB 3.0 (optional)
PCIe 2 x PCIe Gen4 slots + PCIe Gen
• 2 x16 Gen4 (x16 connector) low profile, half length
• 1 x4 Gen3 (x8 connector) low profile, half length
Learn more about our
systems management
solutions
Contact a Dell
Technologies Expert
for Sales or Support
Search our
Resource Library
Follow PowerEdge
servers on Twitter
Learn more about our
PowerEdge servers]
Discover more about PowerEdge servers
© 2022 Dell Inc. or its subsidiaries. All Rights Reserved. Dell, EMC and other trademarks are trademarks of
Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
June 2022
Operating System and Hypervisors • Canonical Ubuntu Server LTS
• Citrix Hypervisor
• Microsoft Windows Server with Hyper-V
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
• VMware ESXi
For specifications and interoperability details, see Dell.com/OSsupport.
OEM-ready version available From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. For more information,
visit Dell.com/OEM.
